Autodose Concrete Batch Plant

As a kind of concrete mixing equipment, autodose concrete batch plant is widely used in various commercial concrete mixing plants and construction sites. Its excellent production efficiency and fully automatic control system have been fully recognized by users of commercial concrete batching plants and engineering concrete batching plants. The core of autodose concrete batching plant equipment is its main engine part, that is, JS concrete mixer.

With the continuous advancement of technology, today's autodose concrete batch plant equipment has been updated for many years. Now it has automated assembly line production, and combined with the design of the site, it is more environmentally friendly and energy-saving. So how does the current concrete batching plant equipment perform automated production? , what is the principle?

The aggregate of fully automatic concrete batching plant is unloaded into the aggregate weighing hopper from the discharge door of the aggregate bin of the batching station for measurement. The measurement system automatically weighs various materials required for a single mixing according to the value set on the control computer. After the measurement is completed, it is unloaded to the running belt, and sent to the waiting silo above the mixer by the belt conveyor, waiting for the next action. While the aggregate is measured and conveyed, the cement powder is conveyed by the screw conveyor to the weighing hopper for measurement. The water is sent to the weighing hopper through the water pump, and the admixture also has a special pumping device.

The measurement of all materials is automatically run under the operation of the control system. After the measurement of all materials is completed, the control system of autodose concrete batch plant sends an instruction to feed materials into the mixer in a predetermined order, and then the host starts to stir and mix the materials to achieve the set stirring. After the time, the material is mixed evenly to form concrete. Then open the unloading door of the mixer and unload the concrete into the concrete truck waiting to be picked up. The next work cycle can then be started.
