Concrete Batching Plant Specifications

The concrete batching plant specifications mainly behaved as the models of concrete mixing equipment. The specification of the concrete batching plant is named according to the discharge size, for example: HZS120 concrete batching plant, the output is 120 cubic meters per hour. Common specifications of concrete batching plants are: HZS25, HZS35, HZS50, HZS60, HZS75, HZS90, HZS120, HZS150, HZS180, HZS240, etc.

Take the common seen concrete batching plant specifications as example, the HZS50 concrete batching plant: The theoretical output is 50m³/h, the host is a JS1000 forced concrete mixer, the external dimensions (length X width X height): 14950x17840x17245 (mm), according to the gradation of sand and stone, choose two warehouses, three warehouses or four The warehouse PLD1600 concrete batching machine, in conjunction with the bulk cement silo, screw conveyor, cement metering, water metering system and centralized control system, forms a simple concrete batching plant. HZS50 concrete batching plants are used in projects.

HZS60 concrete batching plant: The theoretical output is 60m³/hour, using the JS1000 concrete mixer, the overall dimensions (length X width X height): 36500x111300x20400 (mm), which can produce all commercial mixtures with a label below C50 or Semi-dry material, the overall performance of the equipment is close to that of a medium-sized concrete mixing plant.

HZS75 concrete batching plant: The theoretical output volume is 75m³/hour, the external dimensions (mm) (length X width X height): 15950x18840x17245 (mm), the main machine adopts the JS1000 concrete mixer, and the concrete batching machine uses fully pneumatic PLD1600 batching, the machine is a medium-sized concrete mixing plant. If the user wants to invest less, he can choose this type of equipment.

HZS90 concrete batching plant: The theoretical output is 90m³/hour, the overall dimensions (mm) (length X width X height): 51093x19100x21600 (mm), the host uses JS1500 twin-shaft concrete mixer, equipped with PLD2400 concrete batching machine, belt conveyor, automatic centralized control system, etc., are more choices among commercial concrete mixing stations and engineering concrete mixing stations.

The above is the production volume of different concrete batching plant specifications. You can choose which type of concrete batching plant equipment to use according to the actual needs of your own project. Regarding the price of concrete batching plant equipment, the price of each concrete batching plant manufacturer is different. Even if the manufacturer is the same, different models will have price differences. At the same time, the price of concrete batching plant will be affected by factors such as the price of steel in the market, labor costs, brand, competition from the same industry and market demand.
