Features and Structure of Portable Concrete Mixer

A portable concrete mixer for sale mainly refers to a JZC cement mixer, which is a self-falling mixer of double cones and reverse discharges. The mixing tank of a jzc cement mixer for sale is driven by gear rings, rotating forwardly in working and reversely in discharging. It’s able to yield plastic and half dry concretes for buildings, roads, bridges and prefabrication parts. Observed more frequently in daily life, JZC portable concrete mixer machines have a ring gear outside the mixing drum. The other end of the motor is equipped with a pinion. Under the rotation of the motor, the pinion drives the large gear to drive the mixing drum to rotate and mix the concrete. Main models of JZC series include JZC250, JZC350, JZC500 and JZC750, among which JZC750 is a stable mixer which can be used both independently and cooperatively with a distributor to form a simple concrete batching plant. It functions as a JS750 concrete mixer. The others are all of the portable type.

A portable concrete mixer for sale consists of a feeding system, a mixing system and a water supply system. The feeding system include a winch, a loading rack, a hopper and a feed funnel. As the core part of a portable concrete mixer for sale, the mixing system is composed of a mixing tank, a support wheel and a transmission system. The tank is of a double-cone shape with upper and lower mixing blades forming given angles with the mixing cylinder axis. The blades make materials up and down with rotating force of the tank, and agitate repeated in a stable axis. As a result, the mixer is so efficient that concrete of general types can be finished only between 90 to 120 seconds. The water supply system is formed by a motor, a water pump, a adjusting valve, a water suction valve and necessary pipelines.

The features and structure of a portable cement mixer are as above. HAOMEI supply portable concrete mixers of all regular models. Welcome to contact us for more information!
