A mobile concrete mixer pump trailer has wheels to be trailed around. It’s a concrete pump designed especially to meet the rapid development in civil engineering. Equipped with an automatic operation system, the trailer mixer pump integrates raw material feeding, mixing and ready mix concrete pumping. In a word, it combines functions of a concrete batching plant, a concrete mixer truck as well as a trailer concrete pump in a simper and stable way. Capacities include 20m2, 30m3, 40m3, 50m3, 60m3, 90m3 and 120m3. Though in most construction sites a capacity of 60m3 per hour is enough, larger capacities are also available to meet possible requirements for them.
A mobile concrete mixer pump trailer has a traditional concrete drum mixer and a commercial concrete pump integrated together and welded on a frame with wheels and axles. A small truck or a small loader can quickly move between several construction sites or multiple construction points on the same construction site. A pair of high blades and a pair of low blades are welded at one end of the feed port of the mixing drum of the mobile trailer concrete mixer pump. The end of the mixing discharge port is welded with a pair of high discharge blades. The discharge blade is divided into two pieces. When the concrete is ready, the rotation direction of the mixing drum is changed, and the concrete is discharged through the discharge blades. The mixing drum is placed on four supporting wheels, and the power of the mixing motor is transmitted to the active supporting wheels through the reduction box, so that the four supporting wheels drive the mixing drum to rotate.
The mobile trailer concrete mixer pump makes concrete making and construction work faster and simpler. It can be trailed around conveniently, saving time spent on concrete making by concrete mixing plants and delivery by mixer trucks. The pipeline can be arranged over short distances nearby, maximizing the compression of the pipe deployment time. The pump has the reverse pump function, which minimizes pipeline blockage, saves labor costs, and maximizes the compression of operators. Combining all these advantages above, a mobile trailer concrete mixer pump are popular in the pumping of commercial concrete in engineering construction, the green soil, foundation pile grouting, and silt etc.
