Portable concrete trailer pump

Haomei portable concrete trailer pump deals with concrete with aggregates of 10mm to 60mm big. A trailer pump is a pumping machine sending concrete to wanted concreting points directly. It consists of a hydraulic system, a valve system, an auto control system etc. With four wheels, it’s usually trailed to a construction site by a vehicle. The pump is fixed on the ground and pipes are arranged from its outlet to the concreting point. Equipped with an electric or diesel motor, it’s able to send concrete to a height up to 200m, much higher than most pump trucks, the boom length of which are mostly less than 70m. In comparison to similar pumping products, a trailer pump is more advantageous in operation, energy consumption, pumping distance, movement and maintenance.

Haomei portable trailer concrete pump has the following technical features. First, it’s designed by combining pressure difference induction commutation technology and electro-hydraulic proportional buffer technology. This endows it with abilities of filtering impurities by an open system self-circulation and reversing closed system with a small impact. As a result, the hydraulic oil cleanliness is high and the temperature is low. This improves system efficiency, reduces wear between parts, extends service life, and reduces maintenance costs. The high-pressure and large-flow electro-hydraulic control main valve helps optimize the flow path design and integrated valve group, with short reversing time, small pressure loss, low temperature rise, and high reliability. The auto-control system can monitor and diagnose more than 50 faults in real time, effectively shortening the troubleshooting time by 70%. When the pump is repaired, the concrete piston can be automatically returned to the water tank, saving time and energy.

Haomei supplies different models of portable trailer concrete pumps to meet your selection choice. The pump saves power by 25% overall. The service life of the discharge port and the transition sleeve is as high as 6 to 80 thousand cubic meters; the service life of the concrete piston can reach 2 to 3 thousand cubic meters; the service life of the glasses plate is 5 to 80 thousand cubic meters, and the service life of the cutting ring is 2 to 4 thousand cubic meters; The service life of the cylinder is 10~14 million cubic meters.
